White autoclave 8 liters class B with USB Warranty details Safety - The cycle does not start if the door is not properly closed. - The automated double hydraulic locking safety device prevents the door from opening while the chamber is under pressure. - Safety valves prevent pressure generator and camera. - A safety thermostat prevents overheating in the chamber and generator. - An automatic safety lock prevents accidental door opening during the sterilization process protector automatically cuts off electrical power if there is a short circuit or the power supply is not very stable. - Failure alarm indicates a cycle failure and detailed error code. - Door alarm indicates that the door is not secured. - Low water alarm indicates when the water tank is empty or too full. Technical specifications - Voltage: 220-240 VAC; 50/60 Hz; 10A - Chamber dimensions: 170 x 320 mm - Tray size: 130 x 265 mm - Circuit breaker: F16A / 400V - 2000W - Rated power: 1500 VA - Sterilization temperature: 121 °C / 134 °C - Distilled water tank capacity: 2.5 L - Operating temperature: 5 °C / 40 - Relative humidity: Max. 80%, non-condensing - External dimensions: 420 x 370 x 525 mm - Net weight: 37 kg - Maximum noise level: <70 dB - Atmospheric pressure: 76 kPa / 106 kPa Maintenance and error message guide for your sterilizer MAINTENANCE OF YOUR AUTOCLAVE ERROR MESSAGE GUIDE Components - Distilled water tank - LCD screen - Control panel - Main switch - Key for draining distilled and used water - USB port - Safety valve - Ventilation grille - Locking system - Power cable - Label Included accessories - Sterilizer - USB - 2 instrument trays - Tray support - Handle for tray extraction - Tool to adjust the door - 2 drain hoses - Door advice - Instruction manual Regulation - 93/42 / EEC Medical care directive. - 97/23 / EEC Pressure equipment directive. - EN 13060 Small steam sterilizers. - EN 61326, EN 61000 EMC. - EN 61010-1, UL 61010-1 Safety requirements. - EN 61010-2-040, IEC 61010-2-040 Particular requirements for steam sterilizers used for processing medical materials. Autoclave step-by-step process 1. Open the door, take the tools and accessories found in the sterilization chamber, remove the packaging and clean them. 2. Plug the power cord into an appropriate power source. 3. Connect the printer (sold separately). 4. Start-up: the main switch is
